JDX5310JXFJP32 fire truck is a combination of water, foam, high jet three functions in a new class of high-lift truck. It is a domestic advanced level of multi-purpose fire fighting vehicles. The car is used electro-hydraulic proportional and off centrally control technology with fully hydraulic drive, three telescopic + folding side arranged a fire truck. The car used Mercedes-Benz chassis converted Actro3344 II; with HALE RSD1500 type fire pump, using AKRON 3578 + 5177 electric gun monitor, with big flow, long range; at the same time the car comes with 4.8 tons water and 1.9 tons foam tank, in a remote location away from the water fire fighting independently.
Chassis
| Manufacturer | Mercedes-Benz |
| Model | Mercedes Actros3344 |
| Drive Type | 6 × 4 |
| SCBA | Rear rack installation four SCBA |
| Wheelbase | 4500 + 1350 mm |
| Chassis weight | 9230Kg |
| Maximum allowable load | 23700Kg |
| Maximum speed | 104Km / h |
| Engine | V-type 6-cylinder turbocharged and intercooled diesel engine |
| Model | Mercedes-Benz OM501 LA |
| Maximum engine power | 320Kw / 1800r / min |
| Maximum torque | 2100N.M / 1080rpm |
| Emission standard | Euro IV |
| Transmission | Mercedes-Benz G240-16, fully synchronized gearbox. |
Fire fighting systems
1. Fire performance parameters
Water / foam range: ≥65 / 60m
Foam mixer ratio: 6% (manual adjustment)
2. solution tank
Manufacturing: Shanghai Jindun Special Vehicle Equipment Co., Ltd.
Capacity: Water: 4800Kg, Foam: 1900Kg
Structure: damping rubber flexible support, which consists of longitudinal and transverse anti-swing plate is mounted on the sub-frame;
Equipment: 2 individual openings with quick-locking and opening device;
2 level indicator;
2 outfalls, with stainless steel or brass ball valves;
Within a water inlet;
FAQ:
1. Q:Are you a factory or a trade company?
A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the biggest factories for special vehicles in China.
2. Q:Where is your factory located?
A:We are located in Shanghai Province,China.
3. Q:What's your payment method?
A: T/T and L/C are preferred.
4.Q:Do you arrange shipment for the vehicles?
A:Yes, we can arrange shippment based on trade terms.
5. Q: How is the packing?
A:All the packing comply with exporting standard.
6. Q: What's your main product?
A: Our main product include : water & foam tank trucks, CAFS fire trucks, chemical fire trucks, emergency rescue vehicles, lighting trucks, aerial ladder and platform trucks, airport fire trucks, water tower fire trucks and other general fire trucks. The products have been sold to more than 20 countries.
Any other questions, please do not hesitate to contact with us.
