| الطراز | Mercedes Benz G240-16, all synchronous transmission |
| Speed ratio | 16 forward gear, 2 reverse gear |
| Shift type | Mercedes Benz Telligent® intelligent shift system |
| Water pump PTO | Mercedes Benz NMV200 engine full power PTO |
| Speed ratio | 1.48 |
| Maximum output torque | 1500Nm |
| دوران | counter clockwise (same as the engine rotation direction) |
| Output position | the top of the middle, 120mm tooth flange output |
| Other | for long time operation |
| Oil pump PTO | Mercedes Benz MB1b gearbox PTO |
| Speed ratio | 1.24 |
| Maximum output torque | 700Nm |
| دوران | counter clockwise (same as the engine rotation direction) |
| Output position | at 4 o'clock direction, 100mm tooth flange output |
| Other | for long time operation |
الأبعاد
| العنصر | unit | parameter |
| Dimensions (length x width x height) | مم | 10720×2500×4000 |
| Front suspension | مم | 1440 |
| قاعدة العجلات | مم | 4500+1350 |
| Rear suspension | مم | 2950 |
| Extension | مم | 250 |
| Wheel distance | مم | Front 2050 rear 1800 |
Ladder performance
| العنصر | unit | parameter |
| Ladder section number | 4 | |
| Ladder length | ||
| Full contraction | m | 9.65 |
| Full extension | m | 30.05 |
| Stand up | ? | -10~75 |
| angle of rotation | ? | 360 |
| Max height | m | 30.7 |
| Maximum amplitude | m | 18.2 |
| Lifter load | N | 1800 |
| Working bucket load | N | 4000 |
Steering system
- Mercedes Benz 6/LS LS 8 steering device, hydraulic power.
- Steering oil level monitoring and warning.
- Multi function steering wheel, height and angle adjustable, pneumatic locking.
Brake system
- Benz Telligent® intelligent braking system,
- With ABS (ABS) function and Acceleration Skid control (ASR) function.
- Front and rear disc brake.
- Double loop compressed air brake, constant brake pressure of 10 bar.
- Auxiliary brake system and exhaust brake system for enginenormal open valve.
- Heated type long-actingcompressed air dryer.
- In slope starting auxiliary function.
- Brake pipe leakage protection (hand brake release device).
FAQ:
1. Q:Are you a factory or a trade company?
A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the biggest factories for special vehicles in China.
2. Q:Where is your factory located?
A:We are located in Shanghai Province,China.
3. س: ما هي طريقة الدفع الخاصة بك؟
ج: تفضيل T/T و L/C.
4. س: هل تقوم بترتيب الشحن للمركبات؟
ج: نعم، يمكننا ترتيب الشحن بناءً على شروط التجارة.
5. س: كيف هو التعبئة؟
ج: جميع التعبئات تتوافق مع المعايير التصديرية.
إذا كانت لديك أي أسئلة أخرى، فلا تتردد في الاتصال بنا.
