4600mm Wheelbase 6 Seats Fire Fighting Truck 3.57m/Min Traction
4600mm Wheelbase 6 Seats Fire Fighting Truck 3.57m/Min Traction - Image 2

4600mm Wheelbase 6 Seats Fire Fighting Truck 3.57m/Min Traction

Λεπτομέρειες προϊόντος:

  • Διαστάσεις
    9000??2500??3500mm
  • Full Load Mass
    14990 Kg
  • Θέση
    6
  • Maximum Torque
    1390N?m
  • CIMC Tianda stands as a leader in providing advanced airport fire truck solutions that are both reliable and innovative. In the highly specialized world of airport firefighting, the need for quick response times and effective suppression systems is paramount. CIMC Tianda’s fire trucks are designed specifically to meet these requirements, ensuring enhanced safety and efficiency at airports around the globe.
    Isuzu 16 Tons Water Tanker
  • Μέγ. Ταχύτητα
    100Km/h
  • Μεταξόνιο
    4600mm
  • Weight
    228kW
  • Τόπος Προέλευσης
    Σαγκάη Κίνα
  • Όνομα Μάρκας
    CIMC
  • Πιστοποίηση
    ISO9001, CCC
  • Αριθμός Μοντέλου
    JY98
  • Ελάχιστη Ποσότητα Παραγγελίας
    1 μονάδα
  • Modern fire trucks have undergone significant advancements, incorporating innovative technologies to enhance safety and efficiency in firefighting operations. Denver International Airport (DEN) is at the forefront of these developments by integrating advanced systems that address the unique challenges of airport firefighting.
    negotiable
  • Χρόνος Παράδοσης
    180days
  • Όροι πληρωμής
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
Κωδικός προϊόντος: M2518 Κατηγορία:

30% Maximum Climbing Ability Rescue Fire Fighting Vehicle 100km/H Maximum Speed

JY98/H5 rescue fire truck is a fire truck that modified with SINOTRUK HOWO chassis. It has many functions such as demolition, traction, lifting, lighting, etc. It can deal with accidents like traffic accidents and natural disasters.

Model: SG65-41000G (Interstellar)

Lifting Height: 6.45m

Terrain clearance: ≥7.5m

Control system operating voltage: DC24V

Lamp operating voltage: 220V

Lamp power: 1000W

Horizontal rotation angle of the lamp: 360°

Vertical rotation angle of the lamp: 360°



Electric winch

Yes N12000XF(US Champion)

Voltage 24V

Winch rope length 38m

Maximum tension of winch 5t

Traction speed 3.57m/min

Deflection angle 10°



Model: SQ5ZK2(XCMG)

Maximum lifting mass: 5000kg

Maximum lifting moment: 10.5T.m

Swing moment: 1.2T.m

Maximum working range: 8m

Rotary range: 370°

System rated pressure: 30MPa
