Safety device and system
A). Automatic Working Range Limit
Boom only moves in limited area, the boom will determine the outreach and slow down automatically before 1m of the work limit according to the working height and change of amplitude.
B). Weak Jack Control Warning System
If the stabilizer blade sink on the ground due to soft ground, the computerized control system will send warning alarm (warning flash light and warning alarm) to alert the operators. This prevent the whole vehicle to lose its stability and roll over.
C). Upper and Lower Interlock Device
Automatic Switch control valve on the hydraulic system is equipped to ensure safety. Operator can’t operate the whole boom upper superstructure before the outriggers are stabilized and leveled the whole ladder fire truck firmly on the ground. If boom is being operated and not retracted back to the support bracket, the outriggers cannot be operated.
D). Automatic Deceleration/Stop Device
The boom will decelerate and stop automatically 1m before reaching the outreach limit. This mechanism effectively guarantee smoother movement, higher safety and reliability. The screen of control station has text alert until the platform reaches the limit to stop automatically.
| Dimension:(L×W×H) | 13600×2500×3900mm | ||
| Full mass | 42600kg | ||
| Max running | ≥85km/h | ||
| outrigger | structure | H style | |
| longitudinal | 8690mm | ||
| transverse | 7035mm | ||
| Time of Boom raise up at rate height and rotation with 90 ° | ≤310s | |
| Water system | ||
| αντλία | American WATEROUS CX centrifugal fire pump flow:100 L/S @ 1.0 Mpa80 L/S @ 1.60Mpa Inlet flange:DN150,outlet flange:DN100 | |
| Παρατηρητής πυρκαγιάς | American Elkhart:Scorpion RF 8294-EXM+SM-1250E,water/foam use electronic control monitor. Flow adjustment 1150——4800L/min??working pressure 0.55MPa. reach(water)≥55m. reach(foam)≥50m.(the reach will be different depending on water flow) Swivel angle ±45 degree?? up angle 90 degree??depression angle 35degree. ≥100 m wireless control . | |
| Foam head | Equip with foam monitor head | |
| Water way control | Water way control mode:pneumatic control The position is left side of vehicle | |
Πυρκαγιά plumbing | Down part:stainless pipe + aluminum pipe | |
Upper part: telescopic water pipe: aluminum alloy seamless tube Folding water pipe: aluminum alloy seamless tube Soft connection pipe: rubber soft tube | ||
