USA HALE Pump Foam Fire Truck Q235A Steel & Aluminum Alloy Plate Dual-Use Fire Monitor
Main specfication
4X2 drive, Right Hand Drive
Chassis weight: 5645Kg
Full total mass: 17600Kg
Drive Type: 4 × 2
Wheelbase (mm): 4425
Engine Model: MAN D0836LFL30
Number of cylinders: 6
Type: 4-stroke, water-cooled, four-valve, diesel, turbocharged, intercooled, electronically controlled
Engine power (kW / rpm): 213/2300
Displacement: 6871
Emission standard: Euro 4 standard
Torque (Nm / rpm): 1150/1200 ~ 1750
Transmission type: ZF 9S-1310 OD manual transmission
Number of gears: 9 + 1
設備配置の原則
1, According to combat programming and combat development design equipment integration
2, 人間工学の原則に従って各種設備フレームを設計する。.
3, 使用論理と使用頻度に従って設備を配置する
4, 1-2 アクションで地面またはペダルに立っている任意の設備を取ることができる
5, Fixed all equipment with rust-proof, vibration-proof, anti-drop, scratch-proof special clamp.
| シャーシ | ブランド | MAN (MADE IN GERMANY) |
| シャーシモデル | TGM18.290 4X2 BB | |
| 出力 | 213KW | |
4X2 drive, Right Hand Drive Chassis weight: 5645Kg Full total mass: 17600Kg Drive Type: 4 × 2 Wheelbase (mm): 4425 Engine Model: MAN D0836LFL30 Number of cylinders: 6 Type: 4-stroke, water-cooled, four-valve, diesel, turbocharged, intercooled, electronically controlled Engine power (kW / rpm): 213/2300 Displacement: 6871 Emission standard: Euro 4 standard Torque (Nm / rpm): 1150/1200 ~ 1750 Transmission type: ZF 9S-1310 OD manual transmission Number of gears: 9 + 1 Clutch: Monolithic, dry type, with buffer springs, hydraulicPressure booster PTO type: ZF N109 / 10b Dimensions: ≤8500X2500X3500mm | ||
| Fire-extinguishing Agents | Foam(kg) | 1500 |
| Water(kg) | 5500 | |
消防ポンプ
| Manufacturer:USA HALE Impeller Material: Gunmetal Model:50FB-U60-U normal pressure Rated flow/pressure: 1.0Mpa 3600L/M Water diversion type:Electrical diversion pumpMaximum vacuum degree:??85 kpa Suction height: 7 m Time of drawing water: ≤50s | |
泡比率調整器 | Manufacturer:UK FSA AUTOMATE CO.LTD Model: FSA125 Automatic foam inductor Control unit ratio control: 1??10??AUTOMATIC ADJUSTED,Adjust the scale: 0.1% of the increase or reduction amplitude; After continue to press the button for 5 seconds, 1% increase or reduction amplitude can be gained. Rate of foam concentrate:0.15~7.5L/S, Rate of water:6~125 L/S Display:LCD real-time display the rate of water, foam concentrate & proportion. | |
