Шасси
| Производитель | MAN |
| Модель | TGS33.400 |
| Тип привода | 6×4 |
| Emission standard | Euro 3 |
| Max. total mass | 15000kg |
| ВОМ | Suitable for pump operation |
| Engine Model | MAN D2066LF49 |
| Макс. мощность | 294kw |
Fire pump
| Производитель | Rosenbauer |
| Модель | R600 |
| Поток | 90Л/с |
| Давление | 1.0MPa |
| Отвод воды | Поршневой насос-принтер |
| Макс. степень вакуума | ≥85 кПа |
| Время первичной заливки | ≤80с |
| Авто кольцевой насос пены | PH48x2 |
| Type | Ручной |
| Соотношение смешивания | 3%, 6% |
Dry powder tank
| Dry powder filling capacity | 500Kg |
| Working pressure | 1.2 ~ 1.4MPa |
| Dry powder gun and hose reel | 2 sets (30m) |
| Effective spray rate | 5Kg/s |
| Дальность стрельбы | ≥12m |
- Dry powder tank is a pressure vessel which is mainly welded by Q345R material. It is made of feeding powder port, discharging powder port, nitrogen delivery pipe and discharge powder tube, tank nitrogen delivery pipe is a ring shape which is equipped with multiple intake valves, so that gas and powder can mixing uniformly, with fluidized state. The design of intake valve makes dry powder be inaccessible to nitrogen gas delivery pipe.
- Pressure reducing valve and safety valve :This device use Chinese reducing valve. It is a special pressure reducing valve of dry powder fire extinguishing equipment which has features of reliable performance, small size, large gas supply, safety and convenience.
- Dry powder system control box :Equipped with air source main valve, air filter, in the electric steering box is equipped with solenoid valve, fuse boxes, relay, binding post and so on.
Часто задаваемые вопросы
1. Q: Why should we choose you ?
A: a. We are professional manufacture located in Shanghai city for firefighting trucks products which nearby Pudong International Airport, is easily for customer coming and visiting.
b. We can export directly to overseas customer, no need to deal with trading company and the second price increase will not occur.
c. We have our own R&D team, production workshop, QC management team,international marketing team and after service team.
2. Q:What's the delivery time?
A: a. 20 days delivery upon receipt of advance deposit if we have ready in stock for normal standard model.
b. ISUZU & Chinese brand chassis 3 months upon receipt of advance deposit.
c. European brand chassis 9 months upon receipt of advance deposit.
3. В: Какой у вас способ оплаты?
О: Предпочтительные способы - T/T и L/C.
4. В: Вы организуете доставку автомобилей?
О: Да, мы можем организовать доставку в зависимости от условий торговли.
5. В: Как упакованы товары?
О: Вся упаковка соответствует стандартам экспорта.
Если у вас есть другие вопросы, пожалуйста, не стесняйтесь обращаться к нам.
