139KW Max Power AKRON Fire Monitor Heavy Rescue Fire Truck 4×2 drive
I. Main performance parameters:
The whole vehicle
Dimensions (mm): 6870X2240X3040
Full load permissible weight (kg): 10000
Vehicle total weight (kg): 6125
Fire-extinguishing agents: water + Foam: 3500kg
Number of passengers (incl. driver): 5
Max. Power (kw/hp): 139kw/189hp
แชสซี
Name: ISUZU chassis
Model: QL11009KARY
Drive Type: 4×2
Cab: double cabin (1 + 1 + 3), the rear seat backrests fit with three fixtures for putting Self Contained Breathing Apparatus.
Wheelbase : 3815mm
Chassis weight: 2970Kg
Max. permissible load: 7030Kg
Maximum speed: 110Km/h
Min. turning diameter:??15.2m
Engine: Inline four-cylinder, water-cooled, electronically controlled two-stage, high-pressure common-rail, turbocharged, intercooled, diesel engine electronic control
Type: 4HK1-TCG40
Max. power: 139Kw/ 2600r/min
2.13 Max. torque: 510N.M/1600rpm
Emission standard: China ??
Clutch: Single, dry, diaphragm spring, oil and gas booster
Gearbox: MLD-6Q
- Fuel tank: 100L
JDX5100GXFPM35/B foam fire truck adopts QL11009KARY ISUZU chassis, USA HALE AP32 fire pump, USA AKRON 3430 fire monitor and other fire-fighting equipment. The vehicle has the features of a good structure and reasonable layout, easy operation and maintenance. It is usually used by public security fire brigades in large and medium cities, petrochemical companies and airports and other professional fire brigade.
