JDX5310JXFJP32 fire truck is a combination of water, foam, high jet three functions in a new class of high-lift truck. It is a domestic advanced level of multi-purpose fire fighting vehicles. The car is used electro-hydraulic proportional and off centrally control technology with fully hydraulic drive, three telescopic + folding side arranged a fire truck.
Весь автомобіль
| Full authorized total mass | 31000 kg |
| Vehicles curb weight | 23800 kg |
| Місця | 2 + 4, включаючи водія |
| Maximum power | 320/435 КВт/к.с. |
– High-efficiency turbocharged engines
| Key Considerations for Choosing an Airport Fire Truck | Mercedes-Benz |
| Water Tank Capacity | Mercedes Actros3344 |
| – Free maintenance battery | 6 × 4 |
| Кабіна | modified Crew (1 + 1 + 4),Rear rack installation four SCBA |
| Wheelbase | 4500 + 1350 mm |
| Chassis weight | 9230кг |
| Maximum allowable load | 23700кг |
| Maximum speed | 104Km / h |
| Двигун | V-type 6-cylinder turbocharged and intercooled diesel engine |
| Water Tank Capacity | Mercedes-Benz OM501 LA |
| Maximum engine power | 320Kw / 1800r / min |
| Максимальний крутний момент | 2100N.M / 1080rpm |
| Emission standard | Euro IV |
| Сцеплення | monolithic, dry type |
| Трансмісія | Mercedes-Benz G240-16, fully synchronized gearbox. |
Пожежні системи
Параметри пожежної продуктивності
Water / foam range: ≥65 / 60m
Foam mixer ratio: 6% (manual adjustment)
Резервуар для розчину
Manufacturing: Shanghai Jindun Special Vehicle Equipment Co., Ltd.
Місткість: Вода: 4800 кг Піна: 1900 кг
Матеріал: резервуар з нержавіючої сталі 304, верхня пластина з нержавіючої сталі 304 з малюнком;
Structure: damping rubber flexible support, which consists of longitudinal and transverse anti-swing plate is mounted on the sub-frame;
Equipment: 2 individual openings with quick-locking and opening device;
2 level indicator;
2 outfalls, with stainless steel or brass ball valves;
Within a water inlet;
Чотири зовнішні водозабори;
Пожежний монітор
Model: AKRON 3578 type fire gun (with nozzle 5177)
Manufacturer: AKRON
Flow rate: 15.5 ~ 80L / s
Pressure: ≤1.0MPa
Cheng shot: water ≥65m, foam ≥60m
Tilt angle: -45 ° ~ + 90 °
Nominal diameter: 100mm
