25m Working Height 300L Steel Fuel Tank Water Tower Fire Truck 55L Urea Tank
Application: Class A and B fire fighting.
Scope of application: mainly used for fire fighting of medium and high-rise buildings such as towns, industrial and mining enterprises, petrochemical enterprises, oil tanks, warehouses and other tall buildings.
车辆
| 尺寸（长×宽×高） | 11865×2500×3800 (mm) |
| 总重量 | 39750 (kg) | |
| Water/ foam tank capacity | 12000L /4000L | |
| 座位（包括驾驶员） | 2+4 | |
| Fording depth | 500mm | |
| 最高工作高度 | 25m | |
| Specific power | 9.25 | |
底盘 | 制造商 | FIAT IVECO |
| 模型 | AD410T50 | |
| 驾驶 | 8×4 | |
| 驾驶舱 | 1+1+4 | |
| 轴距 | 1875+3950+1380 (mm) | |
| Chassis Net weight | 10910Kg | |
| Approach angle | 26° | |
| Departure angle | 22° | |
| Min. ground clearance | 310mm | |
| Max. authorized total mass | 41000kg | |
| 最大载重 | 30090kg | |
| 前轴允许载荷 | 2×8500 Kg | |
| 后轴允许载荷 | 2×13000 Kg |
引擎
| 模型 | IVECO CURSOR13 F3BE3681BR |
| Max. engine power | 368Kw/500hp@1900 |
| Max. torque | 2300 @1000 |
| 油箱 | 300L steel fuel tank |
| 排放标准 | China IV |
| Urea tank | 55L |
| 离合器 | Monolithic |
| 变速箱 | ZF 16S 2520 TO manual |
制动系统
ABS function, front axle disc brake/rear axle drum brake
352CC air compressor
轮胎
| Front axle | 4× 385/65 R22.5 highway tires |
| Rear axle | 8× 315/80 R22.5 traction tires |
| Rim | 11.75×22.5/9.00×22.5 |
| 备胎 | 1×315/80 R22.5 highway tire with rim |
FAQ:
1. Q:Are you a factory or a trade company?
A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the biggest factories for special vehicles in China.
2. Q:Where is your factory located?
A:We are located in Shanghai Province,China.
3. 问：你们的付款方式是什么？
答：优先选择电汇和信用证。.
4. 问：你们为车辆安排运输吗？
答：是的，我们可以根据贸易条款安排运输。.
5. 问：包装情况如何？
A:所有包装符合出口标准。.
如有其他问题，请随时与我们联系。.
