底盘
| 制造商 | FIAT IVECO |
| 模型 | ML 100E22 |
| 驾驶 | 4×2 |
| Min. turning radius | 5.2m |
| Min. ground clearance | Front 169mm, rear 172mm |
| Chassis Net weight | 10910Kg |
| Approach angle | 18° |
| Departure angle | 18° |
| 引擎 | IVECO TECTOR 6, F4AE3681B*S |
| Max. authorized total mass | 10000kg |
| 排量 | 5.88L |
| Max. torque | 680N•m/1200~2100r/min |
| 最大功率 | 160kW (217HP)/2700r/min |
| 油箱 | 115L plastic fuel tank, 25L heating type urea tank, Recor oil-water separator with heating |
| Electric Accumulator | 2×12V/110Ah, |
| electric generator | 28V/70A/1690W |
| 变速箱 | ZF 6S700 manual |
| 轴距 | 2790毫米 |
| 转向 | Hydraulic power assisted |
| Front axle | IVECO 5833 |
| Rear axle | IVECO 450721 |
| 轮胎 | 6 x Michelin 2×9.5R17.5 XYZ |
| Brake | ABS system |
消防泵
| 制造商 | HALE |
| 模型 | AP32 |
| Water flow | 1.0MPa 32L/s |
| Max. suction depth | 7米 |
| 引水时间 | ≤35s |
Equipment layout principles
1, According to combat programming and combat development design equipment integration.
2, According to human body engineering principle design all kinds of equipment frames.
3, According to using logic and frequency of use place equipment.
4, 1-2 action can take any equipment standing on the ground or pedal.
5, Fixed all equipment with rust-proof, vibration-proof, anti-drop, scratch-proof special clamp.
