车辆
| 模型 | JDX5180GXFPM70 | |
| 底盘 | 品牌 | MAN (MADE IN GERMANY) |
| Chassis Model | TGM18.290 4X2 BB | |
| 功率 | 213KW | |
| Steering wheel | right hand drive | |
| 底盘重量 | 5645Kg | |
| Full total mass | 17600Kg | |
| 驱动类型 | 4 × 2 | |
| 轴距 | 4425 mm | |
| Engine Model | MAN D0836LFL30 | |
| Number of cylinders | 6 | |
| 类型 | 4-stroke, water-cooled, four-valve, diesel, turbocharged, intercooled, electronically controlled | |
| 发动机功率 | 213/2300 kw/rpm | |
| 排量 | 6871mm | |
| 排放标准 | Euro 4 standard | |
| 扭矩 | 1150/1200 ~ 1750 Nm/Rpm | |
| Transmission type | ZF 9S-1310 OD manual transmission | |
| Number of gears | 9 + 1 | |
| 离合器 | Monolithic, dry type, with buffer springs, hydraulicPressure booster | |
| PTO type | ZF N109 / 10b | |
| 尺寸 | ≤8500X2500X3500mm | |
| Fire-extinguishing Agents | Foam(kg) | 1500 |
| Water(kg) | 5500 | |
Equipment layout principles
- According to combat programming and combat development design equipment integration.
- According to human body engineering principle design all kinds of equipment frames.
- According to using logic and frequency of use place equipment.
- 1-2 action can take any equipment standing on the ground or pedal.
- Fixed all equipment with rust-proof, vibration-proof, anti-drop, scratch-proof special clamp.
常见问题:
1. Q:Are you a factory or a trade company?
A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the biggest factories for special vehicles in China.
2. Q:Where is your factory located?
A:We are located in Shanghai Province,China.
3. 问：你们的付款方式是什么？
答：优先选择电汇和信用证。.
4. 问：你们为车辆安排运输吗？
答：是的，我们可以根据贸易条款安排运输。.
5. 问：包装情况如何？
A:所有包装符合出口标准。.
6. 问：你们的主要产品是什么？
A: 我们的主要产品包括：水和泡沫罐车、CAFS消防车、化学消防车、紧急救援车辆、照明车、 aerial ladder 和平台车、机场消防车、水塔消防车及其他通用消防车。产品已销往20多个国家。.
如有其他问题，请随时与我们联系。.
