i. Working Condition for flatbed crane truck
1,高度: 0-4500m
2,Temperature: -25??–+45??
3,Allowed working condition: solid, stable land, the vehicle should be horizontal
4,Wind force: ≤6 degree
ii. Working Range for flatbed truck with crane
“KAI FAN” Brand KFM5323JQZ25G5(QY25G5)Crane is fully hydraulic telescopic crane, the maximum rated lifting capacity is 25t. It can be applied in various conditions for lifting and installation work, such as industrial and mining establishments, building site, station, sea port, warehouse and so on.
iii. Main Parameters for flatbed truck with crane
| アイテム | 単位 | 価値 | |
作業性能パラメータ | 最大定格荷重 | kg | 25000 |
| 基本ブームの最大リフト力 | kn.m | 970 | |
| Max. Lifting force of the longest main boom | kn.m | 470 | |
| 主ブームの最大高さ | m | 40 | |
| 副ブームの最大高さ | m | 48.2 | |
| Max. Speed of the single rope (the second stage) | m/min | 120 | |
| 作業速度 | Extension time of the lift boom | s | 110 |
| リフトブームのリフト時間 | s | 60 | |
| 回転速度 | r/min | 0??2 | |
| 重量パラメータ | 全体重量 | kg | 31670 |
| 前軸の荷重 | kg | 6850 | |
| Load of the rear axle (duel axle) | kg | 24820 | |
| 移動パラメータ | 最大移動速度 | km/h | 70 |
| 最大勾配能力 | % | 30 | |
| Min. Turning radius | m | 11 | |
| 最小地上高 | m | 0.27 | |
| 接近角 | ° | 16 | |
| デパーチャーアングル | ° | 11 | |
Dimension Parameters | External dimension(length×width×height) | mm | 12790×2500×3460 |
| Vertical span of outrigger | m | 5.35 | |
| アウトリガーの水平スパン | m | 6.1 | |
| 主ブームの長さ | m | 10.3~39.5 | |
| 副ブームの長さ | m | 8.3 | |
| Elevation of boom | ° | -2~80 | |
| シャーシ | モデル | — | TAZ5323J |
| エンジンモデル | — | WP10.270 | |
| Rated power/speed | kW/(r/min) | 199/2200 | |
| Max. Torque/rotate speed | N.m/(r/min) | 1100/1200-1600 | |
FAQ
1. Q: Why should we choose you ?
A: a. We are professional manufacture located in Shanghai city for firefighting trucks products which nearby Pudong International Airport, is easily for customer coming and visiting.
b. We can export directly to overseas customer, no need to deal with trading company and the second price increase will not occur.
c. We have our own R&D team, production workshop, QC management team,international marketing team and after service team.
2. Q:What's the delivery time?
A: a. 20 days delivery upon receipt of advance deposit if we have ready in stock for normal standard model.
b. ISUZU & Chinese brand chassis 3 months upon receipt of advance deposit.
c. European brand chassis 9 months upon receipt of advance deposit.
3. Q: お支払い方法は何ですか？
A: T/TとL/Cが好まれます。.
4. Q: 車両の出荷を手配しますか？
A:はい、貿易条件に基づいて出荷を手配できます。.
5. Q: 梱包はどうなっていますか？
A:すべての梱包は輸出基準に準拠しています。.
6. Q:What's your main products?
A:Our main product include : water & foam tank trucks, CAFS fire trucks, chemical fire trucks, emergency rescue vehicles, pumper fire truck, lighting trucks, aerial ladder and platform trucks, airport fire trucks, water tower fire trucks and other general fire trucks. The products have been sold to more than 20 countries.
他に質問がある場合は、お気軽にお問い合わせください。.
