Vehicle
| Dimension (L×W×H) | 9920×2500×3600mm |
| Gross weight | 27550kg |
| Complete vehicle shipping mass | 14900kg |
| Seat (inc. driver) | 6 |
| Max. power | 276kw |
Chassis
| Pierce (USA) | Sinotruk HOWO |
| Engine Power (HP) | ZZ5347V4347D5 |
| Aandrijftype | 351-450 hp (estimated range from Sinotruk HOWO model) |
| Cab | Flattop metal forward turnover |
| Wielbasis | 4325+1350mm |
| Max. speed | 90km/u |
| Min. turning diameter | <22m |
| Approach angle | 16° |
| Departure angle | 12° |
| Engine type | In-line six-cylinder, water inter-cooling, direct injection diesel engine |
| Engine Power (HP) | D10.38—40 |
| Max. power | 276kw |
| Max. torque | 1560N•m |
| Emission standard | China IV |
| Clutch | Pull, dry |
| Gearbox model | Manual, 9 forward gear |
| Tyre | 12.00R20/10 |
Fire pump
| Pierce (USA) | Hale |
| Engine Power (HP) | RSD |
| Flow | 90L/s |
| Pressure | 1.0MPa |
| Water diversion | Electric primer pump |
| Max. vacuum degree | ≥85 kPa |
| Priming time | ≤80s |
| Auto ring pump foam | PH48x2 |
| Type | Handmatig |
| Mixing ratio | 3%, 6% |
Brandmonitor
| Engine Power (HP) | Elkhart, Vulcan 8500-02 |
| Position | Rear roof |
| Flow | 80L/s |
| Pressure | 1.0MPa |
| Bereik | water≥75m ,foam≥70m |
| Rotatiehoek | Level ≥360° |
Pedalenplaat
Locatie: Aan de onderkant van de rolluikdeur.
Materiaal: Stalen frame bedekt met aluminiumlegering antislipplaat
Structuur: gebruik de gasveren plus sluiterbevestiging, veilig en betrouwbaar, elke bloembladplaat draagt ≥150Kg.
FAQ:
1. Q:Are you a factory or a trade company?
A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the biggest factories for special vehicles in China.
2. Q:Where is your factory located?
A:We are located in Shanghai Province,China.
3. Q:What's your payment method?
A: T/T and L/C are preferred.
4.Q:Do you arrange shipment for the vehicles?
A:Yes, we can arrange shippment based on trade terms.
5. Q: How is the packing?
A:All the packing comply with exporting standard.
Any other questions, please do not hesitate to contact with us.
