Όχημα
| Διαστάσεις (Μ×Π×Υ) | 9945×2500×3950 (mm) |
| Μικτό βάρος | 31000 (kg) | |
| Water/ foam tank capacity | 18550L /4000L | |
| Θέση (συμπεριλαμβανομένου του οδηγού) | 2+4 | |
| Μέγ. Ικανότητα | 276/375(kW/hp) | |
Σασί | Chassis Type | Sinotruk HOWO |
| Yes | ZZ5347V4347D5 | |
| Οδήγηση | 6×4 | |
| Καμπίνα | 1+1+4 | |
| Απόσταση άξονα | 4325+1350 (mm) | |
| Chassis Net weight | 9270Kg | |
| Max. load | 23700κιλά | |
| Μέγιστη ταχύτητα | 90Km/h | |
| Ελάχιστη διάμετρος στροφής | <21.6m |
Fire fighting performance
| Spray flow/pressure | 4200L/min @ 1.6MPa |
| Spray range(water/ foam) | ≥70/65m |
| Αναλογιστής αφρού | 6%(manual) |
Δεξαμενή υγρού
| Chassis Type | Shanghai Jindun special vehicle equipment Co., Ltd |
| Χωρητικότητα | Water: 9300L Foam: 1700L |
| Υλικό | 304 corrosion resistant plate |
| Δομή | Welded frame, shock-reducing rubber |
| Εξοπλισμός | 2× manhole 2×fluid level gauge 2 ×drain outlet with ball valve 2 ×outside suction port, 1×inside filling pipe end 4×outside filling pipe end |
Waterway operation panel
At the tail of pump room.
Λαμπτήρας συναγερμού και λαμπτήρας στροβοσκόπου
In front of the vehicle roof equipped with TBD035181 cylindrical red revolving alarm lamp, LTE595 stroboscope lamp on both side.
