车辆 | 尺寸（长×宽×高） | 10970×2480×3900 (mm) |
| Chassis brand | Mercedes Benz | |
| 座位（包括驾驶员） | 2+4 seats (4 doors) | |
| 最大功率 | 320KW | |
底盘 | 制造商 | Germany Mercedes Benz |
| 模型 | Actros3344 | |
| 驾驶 | 6×4 | |
| 驾驶舱 | 1+1+4 | |
| 轴距 | 4500+1350 (mm) | |
| 整备质量 | 14550Kg | |
| Full loading weight | 28000Kg | |
| Max. running speed | 100公里/小时 | |
| 发动机类型 | V type six-cylinder, inter-cooling, electronic unit pump diesel engine | |
| 模型 | OM501LA.IV/4 | |
| 发动机功率 | 320Kw/1800rpm | |
| 最大扭矩 | 2100N.M | |
| 排放标准 | EURO IV | |
| 离合器 | 单体、干式 | |
| 变速箱 | Manual-automatic |
消防监视器
| 模型 | PLKD80 remote controlled Monitor |
| 流量 | 4800L/min |
| 压力 | ≤1.2MPa |
| 范围 | water≥75m ,foam≥70m |
| Swivel/up/depression angle | -45°?? +90° |
臂架结构
| 2 folding boom, welded with high-strength steel | |
| 最高工作高度 | 20米 |
| 最大工作半径 | 9m |
| Pump flow | 100L/s |
| Boom extending time | ≤60秒 |
| 支腿伸展时间 | ≤35s |
| Hydraulic system pressure | 20MPa |
| Max. wind velocity | 12.5m/s |
| Outrigger longitudinal and transverse | 5200×2070mm |
| Allowed working range: Shown as pic1 | |
Alarm lamp and stroboscope lamp
In front of the vehicle roof equipped with TBD035181 long row alarm lamp, LTE595 stroboscope lamp on both side.
Controller
Finland EPEC2024 imported with original packaging.
FAQ:
1. Q:Are you a factory or a trade company?
A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the biggest factories for special vehicles in China.
2. Q:Where is your factory located?
A:We are located in Shanghai Province,China.
3. 问：你们的付款方式是什么？
答：优先选择电汇和信用证。.
4. 问：你们为车辆安排运输吗？
答：是的，我们可以根据贸易条款安排运输。.
5. 问：包装情况如何？
A:所有包装符合出口标准。.
如有其他问题，请随时与我们联系。.
