4×2 Drive Six Firefighters Rescue Fire Truck with Powerful Crane and Winch

Product Details:

Chassis Brand
ISUZU, MAN Or HOWO (optional)
Dimensions
8340??2460??3380 Mm
Drive Type
4×2
Power
177 KW
Chassis Weight
5170 Kg
Max Speed
95 Km/h
Crew Number
6 (include Driver)
Rescue Equipment
98 Pieces
Lift Lighting Height
6.5 M
Product Name
Rescue And Salavage Fire Vehicle
Place of Origin
SHANGHAI,CHINA
Brand Name
CIMC Jindun
Certification
ISO9001,CCCF, TUV, SGS, SCONCAP, PC
Model Number
JY98
Minimum Order Quantity
1 UNIT
Price
Factory price, negotiable
Packaging Details
Exporting standard package or customized packing
Delivery Time
90 days after sign contract
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
800 units per year

4×2 Drive 6 Firefighters Rescue Fire Truck with Powerful Crane

JY98 rescue fire truck is modified from ISUZU QL1160AMFRY chassis.It equipped with 4X1000W lighting system, Honda ET12000 generator, Finland HIAB 111 B-2CLX cranes and emergency lighting equipment.

I. Vehicle

Dimensions	8340×2460×3380 mm
The full authorized total mass	13000kg
Vehicle kerb mass	12550kg
The number of rescue equipment	98 pieces
Crew number(including driver)	6 person
Maximum power	177/240 kW/hp

II. Chassis:

Model	QL1160AMFRY
Drive form	4×2
Cab	A modified (1+1+4), rear mounted four with air breathing aircraft
Wheelbase	4500mm
Chassis weight	5170Kg
Maximum permissible load	16000Kg
Max speed	95Km/h
Minimum turning diameter	??15m
Engine	Inline six cylinder, four stroke, water cooled, turbocharged engine.
Model	6HK1-TCNG40
Engine maximum power	177Kw/ 2400r/min
Maximum torque	706N.M/1450rpm
Emission standard	China ??
Clutch	Monolithic, dry, helical spring Gear-box MLD-6QManual gearbox.
