4×2 Drive Six Seats Isuzu Chassis Foam Firefighting Truck Vehicle Pump 60L/s

Product Details:

  • Size
    8125??2480??3350mm
  • G.V.W
    15330kg
  • Wheelbase
    4500mm
  • Max. Speed
    85km/h
  • Drive Type
    4×2
  • Seats
    6
  • Max. Power
    177kw
  • Structure
    Rotatable Type
  • Product Name
    Fire Tender Vehicle
  • Place of Origin
    Shanghai,China
  • Brand Name
    Jindun
  • Certification
    ISO9001/CCC/TUV
  • Model Number
    PM60W
  • Minimum Order Quantity
    1 unit
  • Price
    Negotiable
  • Packaging Details
    Standard packing for international export
  • Delivery Time
    90 days
  • Payment Terms
    L/C, D/A, D/P, T/T, Western Union, MoneyGram
  • Supply Ability
    300 units/year
SKU: M2133 Category:

4×2 Drive Six Seats Isuzu Chassis Foam Firefighting Truck Vehicle Pump 60L/s

Fire truck (also called fire fighting vehicle , Fire engine , Fire fighting apparatus , Fire service truck , Fire and rescue truck , fire truck , fire fight truck , Foam fire tank truck , Fire extinguishing foam tanker ) is a vehicle designed primarily for fire fighting operation to extinguish fire efficiently to prevent fire spread , reducing the loss caused by fire maximumly .

Fire Vehicle:

Dimension (L×W×H)8145×2500×3330 (mm)
Gross Vehicle weight16150 (kg)
Kerb weight9600kg
Engine power177kw/241HP
Extinguishing capacityWater:5500L Foam: 550L
CabinDouble cabin, 2+4 persons. the rear cabin backrests fitted with four fixtures to put Self Contained Breathing Apparatus


Chassis:

BrandISUZU
Drive4×2 drive
ModelQL1180XMFRY
Drive typeLeft hand drive
Cabin2+4 (incl. driver), double cabins, four doors
Wheel base4500 mm
Track front1960mm
Track rear1855 mm
Power177Kw/241HP
Chassis net weight5500kg
Max. allowable Loading18000kg
Maximum speed105Km/h
Minimum turning radius≤7.8m
EngineInline six-cylinder, four-stroke, water-cooled,high pressure common rail diesel engine
Displacement7790mL
Model6HK1-TCL
Power177Kw/ 2400r/min
Max. Torque706N.m/1450rpm
Emission standardEURO 5
Clutch45-65mm. Monolithic dry clutch
Diameter380 mm
Pedal free stroke45-65 mm
Biggest angle that can pass when full load (Max. Gradient)≥ 30%
GearboxMLD-6Q Six speeds manual gear box
Speed ratio of each gear6.720/4.244/2.580/1.540/1.000/0.763,R6.823
Tire size11.00-20 16PR
Approaching/departure angle15°/17°
Steering gear modelZDZ-100C
Steering typeCircular ball, Steering wheel
Rear axleR130, Integral, main Reduction ratio5.571
Front axleF063, I-section
Braking systemManual, spring energy storage, acting on the rear wheel
Emergency braking typeCombined with driving braking
Type of auxiliary braking systemExhaust brake
Control type of ABS system4S / 4M (4 channels, 4 sensors, 4 regulators)
ABS system controller modelAPG3550500H1
Front suspension typeLeaf spring
leaf spring number9

Fire fighting truck can be divided into many types:

1. According to vehicle size , There are mini fire fighting truck , Light fire fighting truck , Medium fire fighting truck , Heavy duty fire fighting truck .
2. According to chassis drive type , there are 4*2 fire fighting truck , 6*4 Fire fighting truck , 8*4 fire fighting truck , and off road type 4*4 , 6*6 fire fighting truck .
3. According to chassis brand , There are ISUZU fire fighting truck , Dongfeng fire fighting truck , Foton fire fighting truck , Faw fight fighting truck , Shacman fire fighting truck , Sinotruk fire fighting truck , Mercdes fire fighting truck , etc .
4. According to fire agent , there are water tank fire fighting truck , dry powder fire fighting truck , water / Foam fire fighting truck.



Company Profile:
Jindun as a member of China Fire Protection Association, was certified by TUV System, NFPA and CCCF. By excellent products and innovative technology, we are engaged in developing a “safe, livable and rich society.”

The company specializes in R & D and production of ladder cars, high pressure jet trucks, rail dual purpose fire engines, remote water supply vehicles, climbing platform vehicles, water tank foam cars, AT cars, emergency rescue vehicles, marine fire engines, anti-chemical detection vehicles, anti-chemical and decontamination vehicles, CAFS fire engines, airport fire engines, unmanned fire-fighting tankers, lighting fire engines, gas trucks, etc., and according to the changes of fire market and customer demand, Continue to develop high-end special fire engines and multifunctional and intelligent fire-fighting equipment.
