Vehicle
| Dimension (L×W×H) | 6705×2200×3210mm |
| Gross weight | 8150kg |
| Complete vehicle shipping mass | 3925kg |
| Electric generator rated power | 50kw |
| Seat (inc. driver) | 3 |
| Rated power | 139kw |
Chassis
| Manufacturer | Isuzu |
| Model | QL11009KARY |
| Drive type | 4×2 |
| Cab | Original X-P301 |
| Wheelbase | 3815mm |
| Max. speed | 95km/h |
| Min. turning diameter | ??15 |
| Engine type | In-line four-cylinder, high pressure common rail, water inter-cooling |
| Model | 4HK1-TCG40 |
| Max. power | 139kw |
| Max. torque | 510N•m |
| Emission standard | China IV |
| Clutch | Diaphragm spring, monolithic, dry, hydraulic power assisted |
| Gearbox model | Manual, 6 forward gear |
Onboard equipments
| Item | Description | Qty |
| 1 | 2kg dry powder extinguisher | 1 |
| 2 | Wheel chock block | 2 |
| 3 | triangle warning board | 1 |
| 4 | chassis onboard tools | original |
| 5 | Fire axe | 1 |
| 6 | Spade | 1 |
| 7 | Crowbar | 1 |
Painting
Red paint: cab, body (shutter doors, except decorative strip)
White: wheel fender
Onboard document
- Vehicle operation and maintenance manual
- Chassis operating manual
- Chassis operation and maintenance manual
- Chassis quality warranty card
- Chassis certificate, vehicle certificate, 3C logo
- Engine code copy
- Chassis code copy
- Onboard equipment list
- Follow-up service card
- Hand-over list
