Vehicle
| Dimension (L×W×H) | 6705×2200×3210mm |
| Gross weight | 8150kg |
| Complete vehicle shipping mass | 3925kg |
| Electric generator rated power | 50kw |
| Seat (inc. driver) | 3 |
| Rated power | 139kw |
Chassis
| Manufacturer | Isuzu |
| Model | QL11009KARY |
| Drive type | 4×2 |
| Cab | Original X-P301 |
| Wheelbase | 3815mm |
| Max. speed | 95km/h |
| Min. turning diameter | ??15 |
| Engine type | In-line four-cylinder, high pressure common rail, water inter-cooling |
| Model | 4HK1-TCG40 |
| Max. power | 139kw |
| Max. torque | 510N•m |
| Emission standard | China IV |
| Clutch | Diaphragm spring, monolithic, dry, hydraulic power assisted |
| Gearbox model | Manual, 6 forward gear |
Main lighting system
50kw electric generator, 2x8kw main lamp, pneumatic lifting poker, holder, controller, air compressor, power distribution system, auxiliary lighting.
| Electric generator model | ZD50TFY/4 |
| Rated power | 50 kw |
| Rated current | 72.2A |
| Rated speed | 1500 r/min |
| Poles | 4 |
| Rated line voltage | 400VAC |
| Rated phase voltage | 230VAC |
| Frequency | 50Hz |
FAQ:
1. Q:Are you a factory or a trade company?
A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the biggest factories for special vehicles in China.
2. Q:Where is your factory located?
A:We are located in Shanghai Province,China.
3. Q:What's your payment method?
A: T/T and L/C are preferred.
4.Q:Do you arrange shipment for the vehicles?
A:Yes, we can arrange shippment based on trade terms.
5. Q: How is the packing?
A:All the packing comply with exporting standard.
6. Q: What's the delivery time?
A: 1) 20 days delivery upon receipt of advance deposit if we have ready in stock for normal standard model.
2) ISUZU & Chinese brand chassis 3 months upon receipt of advance deposit.
3) European brand chassis 9 months upon receipt of advance deposit.
Any other questions, please do not hesitate to contact with us.
