Iveco small foam fire truck can be used to quickly extinguish small initial fire. This car is specially designed for effective fire fighting in communities. The foam fire truck has a total weight of 7.8 tons, adopts Iveco chassis ML 100E22, and its driving mode is 4 × 2. IVECO TECTOR 6, F4AE3681B * S six cylinder in-line turbocharged intercooled electronically controlled common rail injection diesel engine, 2200L water tank, 500L foam tank, control fire extinguishing equipment and required accessories for fire rescue work are set in the cab.
Its design enables the vehicle to use not only external water sources and fire hydrants, but also its own storage tank to extinguish the fire. The original American AP32 fire pump is used, with a pump flow of 32 L/s; All connection systems shall comply with Chinese industrial standards or equivalent standards. Both mechanical operation and equipment withdrawal and retrieval are designed based on the principle of safety and speed.
Vehicle basic data
| Dimension (L×W×H) | 5270mm×2200mm×2980mm |
| Gross weight | 7800 (kg) |
| Wheel base | 2790mm |
| Water/ foam tank capacity | 2200L /500L |
| Max. engine power | 160kW(217hp)/2700r/min |
| Emission standard | China V |
| Max. speed | 110km/h |
| Seat (inc. driver) | 2+3 |
| Approach angle | 18° |
| Departure angle | 30° |
| Fire pump flow | 1.0MPa, 32L/s |
Chassis
| Manufacturer | FIAT IVECO |
| Model | ML 100E22 |
| Driving | 4×2 |
| Min. turning radius | 5.2m |
| Min. ground clearance | Front 169mm, rear 172mm |
| Chassis Net weight | 10910Kg |
| Approach angle | 18° |
| Departure angle | 18° |
| Engine | IVECO TECTOR 6, F4AE3681B*S |
| Max. authorized total mass | 10000kg |
| Displacement | 5.88L |
| Max. torque | 680N•m/1200~2100r/min |
| Max. power | 160kW (217HP)/2700r/min |
| Fuel tank | 115L plastic fuel tank, 25L heating type urea tank, Recor oil-water separator with heating |
Fire pump
| Manufacturer | HALE |
| Model | AP32 |
| Water flow | 1.0MPa 32L/s |
| Max. suction depth | 7m |
| Priming time | ≤35s |
Fire fighting system
| Suction inlet | 1×DN100 butterfly valve, electric and manual operation |
| Outside Suction inlet | 1×DN125 suction coupling with stainless steel butterfly valve and lid cover, snap- type |
| Outlet | 2×DN80 ordinary outlet with manual ball value, insertion-type |
| Pump outlet | 10mm stainless steel ball valve, manual |
| Outside liquid inlet | Use G1 1/2’’ manual ball valve and KY40 solenoglyphic tooth coupling |
Electrical system
The main lights in the cab at the top of the long row of lights, public address system with Wail-Yelp alarm whistle, including microphone and 100W loudspeaker. 2 Red and blue alarm lamp on both side. A 70w searchlight is set on the roof of the vehicle.
Onboard document
- Vehicle operation and maintenance manual
- Chassis operating manual
- Chassis operation and maintenance manual
- Chassis quality warranty card
?
