Light weight Q235A Steel Foam Fire Truck With 3500kg Water and Foam Tank
Vehicle
| Dimension (L×W×H) | 9720×2500×3700mm |
| Gross weight | 28000kg |
| Complete vehicle shipping mass | 15350kg |
| Seat (inc. driver) | 2 |
| Max. power | 265kw |
Chassis
| Manufacturer | Daimler |
| Model | Actros3336 |
| Drive type | 6×4 |
| Cab | Manual operation hydraulic forward turnover |
| Wheelbase | 4500+1350mm |
| Max. total mass | 18000kg |
| Max. speed | 95km/h |
| Min. turning diameter | <21m |
| Approach angle | 17° |
| Departure angle | 13° |
| Engine type | V type six-cylinder, inter-cooling, electronic unit pump diesel engine |
| Model | OM501LA.IV/2 |
| Max. power | 265kw |
| Max. torque | 1850N•m |
| Emission standard | China IV/ Euro IV |
| Clutch | Monolithic, dry |
| Gearbox model | Manual 16 forward gear |
Fire pump
| Manufacturer | Rosenbauer |
| Model | R600 |
| Flow | 90L/s |
| Pressure | 1.0MPa |
| Water diversion | Piston primer pump |
| Max. vacuum degree | ≥85 kPa |
| Priming time | ≤80s |
| Auto ring pump foam | PH48x2 |
| Type | Manual |
| Mixing ratio | 3%, 6% |
Pipeline
| Outlet pipeline | 2×DN80 ordinary pressure outlet 1×DN50 ball valve |
| Suction inlet | 1×DN150 suction coupling 1×DN150 pneumatic butterfly valve |
| Monitor pipeline | 1×DN125 monitor pipeline 1×DN125 butterfly valve |
| Residual water outlet | Water cock |
| Pump drive system | NMV200 |
| Drive shaft | High balance precision |
FAQ:
1. Q:Are you a factory or a trade company?
A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the biggest factories for special vehicles in China.
2. Q:Where is your factory located?
A:We are located in Shanghai Province,China.
3. Q:What's your payment method?
A: T/T and L/C are preferred.
4.Q:Do you arrange shipment for the vehicles?
A:Yes, we can arrange shippment based on trade terms.
5. Q: How is the packing?
A:All the packing comply with exporting standard.
Any other questions, please do not hesitate to contact with us.
