Generator
| Power factor | 0.8 |
| Voltage | 380/220V |
| Electric current | 16.5A |
| Frequency | 50HZ |
| Fuel | Gasoline |
Lifting lighting system:
| Manufacturer | Zhejiang interstellar |
| Model | SG 65-41000G |
| AGL | ≥7.5m |
| Lamp power | 4 × 1000W |
| Lamps horizontal rotation angle | 360 ° |
| Lamps vertical rotation angle | 360 ° |
| Lifting rod material | high strength heat treatment 6061 T6 military aluminum material |
| Wind resistance rating: | 10km/h (Level 11 Gale) |
| Luminaire specification | 230V |
| Halogen lamp lighting life | more than 2000 hours |
| Illuminance | > 86000lx |
| Expansion time | less than 60s |
| warranty | ll components for 1 years |
| Remote control type | line control |
| Features | with a reset function, integrated lamp rack, inner line. |
Traction system (right)
Manufacturer: AmericanWARN
Model Series 18-A-2D
Voltage (V) 24
The largest single rope traction (Kg) 8000
Traction rope length 24+6M
Traction rope diameter 12.7mm
Installation position at the front bumper (right)
Truck Cranes
Model XCMG SQ5ZK2
Lifting capacity: 10tm
Rotary torque: 12KN.m
Rotation angle: 400 ° (rear side of safe operating range 180 °)
Outrigger span: 4.87 m
Side girder Features: made of welding high quality profiled steels, two longitudinal beams through a plurality of beam intensity bearing joint of high strength bolt connection. The side beam is installed, use girder structure, to ensure that the original car beam of uniform stress, improve the service life of the girder, and reduce deformation caused by components twisted.
