4×2 drive 7 seats 115km/h IVECO chassis Communication command fire truck
| Dimension (L×W×H) | 6095×2000×3260mm |
| Gross weight | 4000kg |
| Complete vehicle shipping mass | 3925kg |
| Communication command equipment total power | 1000w |
| Seat (inc. driver) | 1 |
| Approach angle | 20° |
| Departure angle | 10° |
| Front/ rear overhang | 1000/1680mm |
Chassis
| Manufacturer | Nanjing automobile(group) corporation |
| Model | NJ6606DA6 |
| Drive type | 4×2 |
| Cab | 570101AB |
| Wheelbase | 3310mm |
| Max. speed | 115km/h |
| Min. turning diameter | ??12 |
| Engine type | In-line four-cylinder, pressure combustion, high pressure common rail, inter-cooling, direct injection diesel engine |
| Model | F1CE0481P |
| Max. power | 107kw |
| Max. torque | 327N•m |
| Emission standard | China IV |
| Clutch | Monolithic, dry, diaphragm ring |
| Gearbox model | Manual, 5 forward gear |
| Steering gear | Pinion and rack |
Vehicle-mounted electric generator
| Model | HONDA EL6500CXS |
| Rated power | 5 kw |
| Voltage | 220V |
| Frequency | 50HZ |
| Fuel | Gasoline |
| Fuel tank capacity | 25L |
| Continuous working hours | 8 hours |
Equipment According to customers requirements, equipped with various kinds of communication equipments, stretcher and medicine cabinet, etc.
