Max. Speed of the single rope 115m/min KaiFan Brand 25T (FAW) Crane 70km/h Max Traveling speed
One. Working Condition
1,Altitude: 0-4500m
2,Temperature: -25??–+45??
3,Allowed working condition: solid, stable land, the vehicle should be horizontal
4,Wind force: ≤6 degree
Two. Standard Equipments
1. FAW CA5305JQZ
2. Main boom assembly
3. Vice boom assembly
4. Hanging hook assembly
5. Windlass assembly
6. Slewing system
7. Electric system
8. Hydraulic system
9. Outrigger
10. Superstructure control system
11. Chassis control system
12. Tool box
Three. Main Parameters
| Items | Unit | Value | |
| Working Performance Parameters | Max. Rated lifting weight | kg | 25000 |
| Max. Lifting force of the basic boom | kn.m | 875 | |
| Max. Height of the main boom | m | 32.45 | |
| Max. Height of the vice boom | m | 40.14 | |
| Max. Speed of the single rope | m/min | 115 | |
| Working Speed | Extension time of the lifting boom | s | 115 |
| Lifting time of the lift boom | s | 80 | |
| Turning speed | r/min | 0~2.4 | |
| Traveling Parameters | Max. Traveling speed | km/h | 70 |
| Max. Grade ability | % | 32 | |
| Min. Turning diameter | m | 20 | |
| Min. Ground clearance | m | 0.265 | |
| Approaching angle | ° | 16 | |
| Departure angle | ° | 11 | |
Weight Parameters | The whole weight of full load | kg | 30000 |
| Load of the front axle | kg | 7000 | |
| Load of the middle-rear axle | kg | 23000 | |
| The whole weight | kg | 29870 | |
Dimension Parameters | External dimension(length×width×height) | mm | 12630×2600×3485 |
| Vertical span of outrigger | m | 5.2 | |
| Horizontal span of outrigger | m | 5.9 | |
| Length of main boom | m | 10.2~32.1 | |
| Length of vice boom | m | 8.1 | |
| Elevation of main boom | ° | -1~80 | |
| Chassis | Model | — | CA5305JQZ |
| Engine model | — | CA6DL1-26E3 | |
| Rated power/speed | kw/(r/min) | 192/2300 | |
| Max. Torque/speed | n.m/(r/min) | 1050/1300-1700 | |
