Strobe Lights Installed Water Tanker Fire Truck With Hydraulic Control Clutch

Product Details:

Chassis Brand
ISUZU
Dimension
6255??1945??2940 (mm)
Gross Weight
6630(kg)
Seat (inc. Driver)
2+3
Drive Type
4×2
Wheelbase
3360mm
Max. Power
88/2900 Kw/hp
Water Capacity
2000L
Chassis Weight
2070kg
Product Name
Water Tanker Fire Truck
Place of Origin
shanghai China
Brand Name
CIMC Jindun
Certification
ISO9001,CCC
Model Number
JDX5070GXFSG20/F
Minimum Order Quantity
1 unit
Price
Negotiable
Packaging Details
Exporting standard package or customized packing
Delivery Time
90 days after sign contract
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
350 units/year

Vehicle

Dimension (L×W×H)	6255×1945×2940 (mm)
Gross weight	6630(kg)
Complete vehicle shipping mass	4255 (kg)
Extinguishant capacity	Water: 2000L
Seat (inc. driver)	2+3
Max. power	88/2900 kw/hp

Chassis

Manufacturer	ISUZU
Model	QL1070A1HWY
Drive type	4×2
Cab	Equipped with 3 air resporator
Wheelbase	3360mm
Chassis net weight	2070kg
Max. allowable load	6725kg
Max. speed	105km/h
Min. turning diameter	??13.6m
Engine type	In-line six-cylinder, four-stroke, water cooling, turbocharged engine
Model	4KH1-TCG40
Max. power	88Kw/ 2900rpm/min
Max. torque	290N.M/1500rpm
Emission standard	China IV
Clutch	Monolithic, dry, diaphragm spring, hydraulic control
Gearbox	MSB manual

Electrical system

The main lights in the cab at the top of the long row of lights, configure the 100W alarm control system; a strobe lights installed on both sides and the middle of each compartment.
