VOLVO 598hp Power Aerial Ladder Fire Fighting Engine With Four Telescopic Booms
Outrigger system
Model:H type
Maximum stretch width??4.7M(front),5.0M(rear)
Operation:
- The control of all supports and legs can also be carried out separately.
- All legs / feet are operated by pressing a button on the control panel of a leg / foot.
Each of the four legs in the horizontal direction can be within the scope of design with arbitrary width extending, computer automatic detection of the extending of the outrigger width. Accordingly, to control maximum span of the ladder.
Vehicle | Dimension (L×W×H) | 13200×2500×3995mm |
| Gross weight | 42600kg | |
| Complete vehicle shipping mass | 39330kg | |
| Seat (inc. driver) | 2 | |
| Engine Power | 440/598 ( kW/hp) | |
Chassis | Manufacturer | Mercedes Benz |
| Model | Actros41602 | |
| Driving | 8×4 | |
| Cabin | Single cab | |
| Wheel base | 1700+4300+1350 | |
| Net weight | 9230Kg | |
| Max. loading | 44000Kg | |
| Max. running speed | 95Km/h (electronic speed limit) | |
| Min. turning diameter | ≤23.1m | |
| Engine type | V type, 8 cylinder in line turbo, middle cool engine | |
| Model | MercedesOM502LA | |
| Max. engine power | 440Kw/ 1800r/min | |
| Maximum torque | 2800N.M/1080rpm | |
| Emission standard | Euro V | |
| Clutch | Dry dual clutch | |
| Transmission | Mercedes G260-16 fully synchronized | |
Full power PTO | NMV200(N56)i=1.48(speedup), Full power | |
PTO of transmission | MB1b(N04)i=1.03/1.24 (speed up) |
Boom Structure | Main boom + four telescopic booms + folding boom, welded with HG70 high-strength steel
| |
| Max. working height | 53m | |
| Max. working radius | 20m | |
| Main boom action angle | -3°??83° | |
| Folding boom action angle | 0°??180° | |
| Turntable slewing | Infinite rotation 360° | |
| Pump flow | 70L/[email protected] | |
| Boom extending time | ≤180s | |
| Outrigger extending time | ≤30s | |
| Hydraulic system pressure | 21MPa | |
| Max. wind velocity | 12.5m/s | |
Outrigger longitudinal and transverse | 6650×6000mm | |
| Pipeline | Water outlet | 4×DN80 ball value coupling, 1×DN125 air drive butterfly valve |
| Suction inlet | 2×DN150 hermaphroditic coupling with lid cover, 1×DN150 air drive butterfly valve | |
| Water injection | 1×DN50 air drive butterfly valve 4×DN80 equip with lid cover | |
| Water supply | 2×DN80 ball value coupling |
FAQ:
1. Q:Are you a factory or a trade company?
A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the biggest factories for special vehicles in China.
2. Q:Where is your factory located?
A:We are located in Shanghai Province,China.
3. Q:What's your payment method?
A: T/T and L/C are preferred.
4.Q:Do you arrange shipment for the vehicles?
A:Yes, we can arrange shippment based on trade terms.
5. Q: How do you make our business long-term and good relationship?
A: 1)We keep good quality and competitive price to ensure our customers benefit ;
2)We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
Any other questions, please do not hesitate to contact with us.
