JY98/H5 rescue fire truck is a fire truck modified with ZZ5207N4617E1 chassis. The fire vehicle integrates multi-functions such as demolition, traction, lifting, lighting, etc. It's performance is reliable, its function is applicable, and it is easy to use. It's mainly used in fire bridages , petrochemical enterprises, military, airport and port terminals in large and medium-sized cities. The vehicle provides a good rescue and rescue means for saving people, dealing with traffic accidents and natural disasters on land.
Structural parameters
Dimensions(length × height × width): 9000×2500×3500mm
Vehicle performance
| Engine rated power | 228kW |
| Maximum torque | 1390N·m |
| Maximum speed | 100km/h |
| Maximum climbing ability | 30% |
| Maximum braking distance | (30km/h initial speed): ≤10m |
| Wheelbase | 4600mm |
| Tread | front:2060; rear:1830 mm |
| Approach angle | 17° |
| Departure angle | 11° |
Axle Load Mass Distribution
| Full load mass | 14990 kg |
| Front axle load mass | 5590 kg |
| Rear axle load mass | 9400kg |
| Crew members(including driver) | 6 |
Illuminating system
| Model | SG65-41000G |
| Lifting Height | 6.45m |
| Terrain clearance | ≥7.5m |
| Control system operating voltage | DC24V |
| Lamp operating voltage | 220V |
| Lamp power | 4×1000W |
| Horizontal rotation angle of the lamp | 360° |
| Vertical rotation angle of the lamp | 360° |
Generation
| Model | EH3135 |
| Rated output power | 13.5 Kva |
| Maximum output power | 14.5 kva |
| Power factor | 0.8 |
| Voltage | 380/220 V |
| Electric current | Each phase 16.5A |
| Frequency | 50HZ |
| Fuel | gasoline |
| Continuous working hours | 6.5 hours |
FAQ
1. Q: Why should we choose you ?
A: a. We are professional manufacture located in Shanghai city for firefighting trucks products which nearby Pudong International Airport, is easily for customer coming and visiting.
b. We can export directly to overseas customer, no need to deal with trading company and the second price increase will not occur.
c. We have our own R&D team, production workshop, QC management team,international marketing team and after service team.
2. Q:What's the delivery time?
A: a. 20 days delivery upon receipt of advance deposit if we have ready in stock for normal standard model.
b. ISUZU & Chinese brand chassis 3 months upon receipt of advance deposit.
c. European brand chassis 9 months upon receipt of advance deposit.
3. Q:What's your payment method?
A: T/T and L/C are preferred.
4.Q:Do you arrange shipment for the vehicles?
A:Yes, we can arrange shippment based on trade terms.
5. Q: How is the packing?
A:All the packing comply with exporting standard.
Any other questions, please do not hesitate to contact with us.
