Vehicle
| Dimension (L×W×H) | 8655×2500×3500mm |
| Gross weight | 13066kg |
| Complete vehicle shipping mass | 12616kg |
| Rescue equipment quantity | 100pcs |
| Seat (inc. driver) | 2+4 |
Chassis
| Manufacturer | MAN |
| Model | TGM 18.290 |
| Drive type | 4×2 |
| Cab | Crew cab |
| Wheelbase | 4425mm |
| Max. total mass | 18000kg |
| Max. speed | 96km/h |
| Min. turning diameter | <15.6m |
| Engine type | In-line six-cylinder, inter-cooling, high pressure common rail, electronic control |
| Model | D0836LFL30 |
| Max. power | 213kw |
| Max. torque | 1150N.M |
| Emission standard | China IV |
| Gearbox model | ZF 9S-1310 OD Manual |
Onboard equipment
| No. | Item | Qty |
| 1 | 2kg Fire Extinguisher | 1 |
| 2 | Tyre chock block | 2 |
| 3 | triangle warning sign | 1 |
| 4 | Chassis onboard tool | |
| 5 | Spare wheel | |
| 6 | Fire axe | 1 |
| 7 | Spade | 1 |
| 8 | Hammer | 1 |
| 9 | Crowbar | 1 |
| 10 | Lifting skids | 2 |
| Note: The above equipment is equipped in a vehicle by us, but the rest of all kinds of rescue equipment is equipped by users themselves. We are responsible for packing. | ||
