The JY100 emergency rescue fire truck is modified from MAN chassis. It is equipped with 100 piece/set of equipment, such as truck-mounted crane, the winch , the lifting lighting system and the Honda generator. The structure and layout of the whole vehicle are reasonable, and the operation and maintenance are simple.
It is suitable for the fire brigade in large and medium-sized cities, petrochemical enterprises, airports and other professional fire brigades to deal with emergencies. The shape, structure and performance of maintenance system of the whole vehicle meet the level and service life requirements of similar imported vehicles from abroad.
Traction system
| Model | M12000 |
| Manufacturer | Warn |
| Winch cable max. length | ≥38m |
| Voltage | 24V |
| Winch cable diameter | 9.5m |
| Winch max. pull | 5440kg |
| Position | Front bumper |
Electric generator
| Model | EH3135 BINSON |
| Rated output power | 13.5kVA |
| Max. output power | 14.5kVA |
| Power factor | 0.8 |
| Voltage | 380/220V |
| Electricity current | 16.5A/per phase |
| Frequency | 50HZ |
| Fuel | Petrol |
Chassis
| Manufacturer | MAN |
| Model | TGM 18.290 |
| Drive type | 4×2 |
| Cab | Crew cab |
| Wheelbase | 4425mm |
| Max. total mass | 18000kg |
| Max. speed | 96km/h |
| Min. turning diameter | <15.6m |
| Engine type | In-line six-cylinder, inter-cooling, high pressure common rail, electronic control |
| Model | D0836LFL30 |
| Max. power | 213kw |
| Max. torque | 1150N.M |
| Emission standard | China IV |
| Gearbox model | ZF 9S-1310 OD Manual |
FAQ:
1. Q:Are you a factory or a trade company?
A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the biggest factories for special vehicles in China.
2. Q:Where is your factory located?
A:We are located in Shanghai Province,China.
3. Q:What's your payment method?
A: T/T and L/C are preferred.
4.Q:Do you arrange shipment for the vehicles?
A:Yes, we can arrange shippment based on trade terms.
5. Q: How is the packing?
A:All the packing comply with exporting standard.
6. Q: What's the delivery time?
A: 1) 20 days delivery upon receipt of advance deposit if we have ready in stock for normal standard model.
2) ISUZU & Chinese brand chassis 3 months upon receipt of advance deposit.
3) European brand chassis 9 months upon receipt of advance deposit.
Any other questions, please do not hesitate to contact with us.
