.Chassis
| Manufacturer | Mercedes benz |
| Model | Actros3344 |
| Drive | 6×4 |
| Cab | Mercedes Actros middle-sized cab |
| Crew department | 4 passengers, with 4 air breathing apparatus at the back row |
| Wheelbase | 4500+1350 mm |
| Engine max. power | 320kw/440hp |
| Chassis net weight | 9340kg |
| Max. allowable load | 33000kg |
| Max. speed | 100km/h |
| Min. turning diameter | <19.8m |
| Engine | V type, 6 cylinder inline turbo, middle cool diesel engine |
| Model | Mercedes OM501LA |
| Max. power | 320kw/ 1800r/min |
| Max. torque | 2100 N.M /1080 rpm |
| Emission standard | Euro 4, use Blue-Tec SCR catalyze technology |
| Clutch | Single dry clutch 430mm |
| Gearbox | Mercedes G240-16, full synchronizing, 16 forward gear, speed ratio 11.7-0.69, 2 reverse gear |
| PTO model | NMV200 full power |
| Speed ratio | 1.48 |
| Tyre | 315/80R22.5 |
Pump drive system of fire pumper truck
PTO
- NMV200(full power PTO)
Tanks
Capacity(kg): water: 7000 foam: 1000
Material: High quality stainless steel 304 ,bottom plate thickness: 4mm,dummy plate thickness: 3mm
Structure: tanks are equipped with vertical and horizontal anti-swing plates.
Equipment: 2 entrance holes
2 overflow devices
2 water lever sensor
2 drains mounted with DN50 valve
4 DN80 filling pipe end
Technical requirements: in line with the relevant provisions of GA39.4-92
FAQ
1. Q: Why should we choose you ?
A: a. We are professional manufacture located in Shanghai city for firefighting trucks products which nearby Pudong International Airport, is easily for customer coming and visiting.
b. We can export directly to overseas customer, no need to deal with trading company and the second price increase will not occur.
c. We have our own R&D team, production workshop, QC management team,international marketing team and after service team.
2. Q:What's the delivery time?
A: a. 20 days delivery upon receipt of advance deposit if we have ready in stock for normal standard model.
b. ISUZU & Chinese brand chassis 3 months upon receipt of advance deposit.
c. European brand chassis 9 months upon receipt of advance deposit.
3. Q:What's your payment method?
A: T/T and L/C are preferred.
4.Q:Do you arrange shipment for the vehicles?
A:Yes, we can arrange shippment based on trade terms.
5. Q: How is the packing?
A:All the packing comply with exporting standard.
Any other questions, please do not hesitate to contact with us.
