HALE pump 6000L/min imported chassis airport fire truck 6 seats monitor 4800 L/min 6×6 drive
Airport fire truck can be used for rapidly rescuing aircraft passengers and crew, and extinguishing fire. It is also applicable to building firefighting.
The total weight of airport fire truck is 29 tons, using the German Mercedes-Benz ACTROS 3360 chassis, 6 × 6 drive, Germany Mercedes-Benz OM502LA water-cooled V-type eight-cylinder 24-valve turbocharged and intercooled diesel engine electronically controlled common rail injection, 9500L water tank, 1200L foam tank, equipped with controlling fire-fighting equipment and rescue equipments in the cab.
Power System
| Manufacturer | DCEC CUMMINS engine |
| Model | L375 type supercharger-air cooled diesel engine |
| Rated power | 276kW/2200rpm |
| Max. torque | 1480N.m/1400rpm |
| Low idle speed | 800rpm |
| Engine working temperature | -20??+40??, common workload 80% |
Water Pump
| Manufacturer | America HALE |
| Model | RSD100 |
| Flow rate | Normal pressure: 1.0Mpa, 6000L/min. |
| Driving | By the rear-mounted DCEC CUMMINS engine power ≤195kw / 2200 rpm |
| Vacuum device | Electric primer pump, Max. suction depth is 7.5m, vacuum ratio 85%,prime time ≤80s |
| Location | mid-mounted |
Pipeline material: pipeline and ball valve are made of stainless steel (304)
- Tank water inlet: two for each side (total is four), with strainer
- Tank suction pipe: DN150 butterfly valves with electric and manual operation.
- Outer suction tube: DN150 suction port with butterfly valve
- The left outlet: 2 DN80 normal pressure outlets. With manual valve
- The right outlet: 2 DN80 normal pressure outlets. With manual valve
- Water cannon tube: a DN100 normal pressure pipe, connected to the roof cannon, by pneumatic valve control switch.
Cab
| Type | Mercedes-Benz Actros long cab, interior standing height of 1400mm, a four-point cab suspension, strengthened rear suspension, cab hydraulic turning device, steel sunroof, central locking, fire red, high-comfortable driver's seat with air spring, one co-driver seat, automatic environmental protection air-conditioning system (RA134 coolants, no Freon), CD radio, central locking, electric heated rearview mirrors, electric heated wide-angle, left in a reasonable position GPS and VHF communication facilities space, and 12V power socket. |
| Door | 2 doors, electric power window |
| Seat | 1+1+4 (4 is for sleeping seats.) |
| Interior configuration | driver seat can be adjustable, co-driver seat can be folded. CD radio, air-conditioner system, ventilation system, dust filter unit etc. |
