Vehicle
| Dimension (L×W×H) | 9720×2500×3700mm |
| Gross weight | 28000kg |
| Complete vehicle shipping mass | 15350kg |
| Seat (inc. driver) | 2 seats |
| Max. power | 265kw |
Chassis
| Manufacturer | Mercedes Benz Daimler |
| Model | Actros3336 |
| Drive type | 6×4 |
| Cab | Manual operation hydraulic forward turnover |
| Wheelbase | 4500+1350mm |
| Max. total mass | 18000kg |
| Max. speed | 95km/h |
| Min. turning diameter | <21m |
| Approach angle | 17° |
| Departure angle | 13° |
| Engine type | V type six-cylinder, inter-cooling, electronic unit pump diesel engine |
| Model | OM501LA.IV/2 |
| Max. power | 265kw |
| Max. torque | 1850N•m |
| Emission standard | Euro IV |
| Clutch | Monolithic, dry |
| Gearbox model | Manual 16 forward gear |
Fire pump
| Manufacturer | US HALE |
| Model | RSD |
| Flow | 6000L/M |
| Pressure | 1.0MPa |
| Water diversion | Piston primer pump |
| Max. vacuum degree | ≥85 kPa |
| Priming time | ≤80s |
| Auto ring pump foam | PH48x2 |
| Type | Manual |
| Mixing ratio | 3%, 6% |
Product advantage:
1.Factory export department directly sale
2.Export experience more than 10 years
3.Cheap / competitive price, high quality ,you get more than your paid
4.With CCC, ISO , BV approved
5. The heart of the service, rational design
Roll on roll off (RORO) ship
It's the specialized ship to transport cars and trucks, which has power wheel, it's the best way of truck transportation.
Bulk carrier ship
It's the specialized ship to transport grain, coal, ore, salt, cement ,etc, dry and bulk goods, can also used to transport trucks,price is cheap, but the truck always be put on the deck, sea water will damage the truck painting.
Container ship
It's well-known shipping way, and also the highest cost among these three ways. Few sea port only container ship can arrive, so sometimes, we have to use container ship.
FAQ:
1. Q:Are you a factory or a trade company?
A: Shanghai Jindun Special Vehicle equipment Co., LTD is one of the biggest factories for special vehicles in China.
2. Q:Where is your factory located?
A:We are located in Shanghai Province,China.
3. Q:What's your payment method?
A: T/T and L/C are preferred.
4.Q:Do you arrange shipment for the vehicles?
A:Yes, we can arrange shippment based on trade terms.
5. Q: How is the packing?
A:All the packing comply with exporting standard.
6. Q: What's your main product?
A: Our main product include : water & foam tank trucks, CAFS fire trucks, chemical fire trucks, emergency rescue vehicles, lighting trucks, aerial ladder and platform trucks, airport fire trucks, water tower fire trucks and other general fire trucks. The products have been sold to more than 20 countries.
Any other questions, please do not hesitate to contact with us.
